Description
The Voltas HYD-6K-H6 single-phase hybrid inverter is a cutting-edge solution for maximizing solar energy usage and efficient battery management. It is tailored for both residential and commercial settings. This durable and adaptable inverter delivers reliable performance across various energy needs. Compatible with lead-acid and Li-ion batteries, the inverter operates within a 40-60 V voltage range and supports up to 140 A for charging and discharging. Its 3-stage charging curve ensures optimal battery maintenance, and an optional external temperature sensor further fine-tunes charging conditions for improved efficiency. Key specifications include a maximum DC input power of 6,000 W and a PV input voltage of 370 V (with an operational range of 125-500 V). The MPPT voltage range spans 150-425 V and features two MPPT trackers for enhanced energy harvesting. It provides a rated AC output power of 6,000 W and a peak output of 7,200 W, with a power factor of 0.8 (leading to 0.8 leading), delivering reliable AC output.
Technical specifications
- Max. DC input power: 9000W
- Max. DC input voltage: 550V
- MPPT working voltage range: 90V – 500V
- Number of independent MPPT/strings per MPPT: 2/1
- MPPT max. current: 15×2A
- Start-up voltage: 100V
